• Clamp end.
• Body Working Pressure: 1000 PSI WOG.
• Clamp End Working Pressure: 200 PSI WOG.
• Working Temperature: -4°F to 300°F.
• Investment casting.
• Fully Encapsulated.
• Locking handle.
• ISO 5211 mounting pad.
• Full port design.
• Other configurations available upon request. Call Sanitube for information.
| Size (Tube OD) | Part Number | Dimensions | Torque (in/lb) | Weight (lbs.) | ||||||||||||
| D | W | H | H1 | H2 | H3 | L | G | K | J | N | ISO 5211 | Breakaway | Action | |||
| 1/2″ | TCBVS-050 | 0.380 | 5.560 | 2.500 | 1.910 | 0.710 | 0.510 | 3.583 | 1.000 | 1.460 | 1.000 | 0.260 | F03 | 31 | 20 | 1.7 |
| 3/4″ | TCBVS-075 | 0.620 | 5.560 | 2.620 | 2.040 | 0.740 | 0.510 | 4.016 | 1.000 | 1.460 | 1.000 | 0.260 | F03 | 47 | 32 | 2.1 |
| 1 “ | TCBVS-100 | 0.870 | 5.560 | 2.730 | 2.150 | 0.710 | 0.510 | 4.528 | 1.170 | 1.650 | 1.990 | 0.260 | F04 | 105 | 58 | 3.0 |
| 1-1/2″ | TCBVS-150 | 1.370 | 7.410 | 3.960 | 3.250 | 1.180 | 0.770 | 5.433 | 1.390 | 1.970 | 1.990 | 0.330 | F05 | 238 | 115 | 5.9 |
| 2 “ | TCBVS-200 | 1.880 | 7.410 | 4.350 | 3.600 | 1.140 | 0.770 | 6.181 | 1.390 | 1.970 | 2.520 | 0.330 | F05 | 256 | 115 | 9.2 |
| 2-1/2″ | TCBVS-250 | 2.370 | 10.240 | 5.480 | 4.610 | 1.480 | 1.020 | 6.693 | 1.950 | 2.830 | 3.050 | 0.470 | F07 | 900 | 288 | 19.2 |
| 3 “ | TCBVS-300 | 2.870 | 10.240 | 5.830 | 4.990 | 1.500 | 1.020 | 7.796 | 1.950 | 2.830 | 3.580 | 0.470 | F07 | 1650 | 230 | 31.3 |
| 4 “ | TCBVS-400 | 3.840 | 11.610 | 6.890 | 6.380 | 2.050 | 1.380 | 9.528 | 2.840 | 3.700 | 4.690 | 0.630 | F10 | 2027 | 345 | 45.2 |
| Component | Description | Material | |||
| 1 | Body | T316 Stainless Steel | |||
| 2 | Cap | T316 Stainless Steel | |||
| 3 | Ball | T316 Stainless Steel | |||
| 4 | Seat | PTFE | |||
| 5 | Seal | PTFE | |||
| 6 | Thrust Washer | PTFE | |||
| 7 | Stem Packing | PTFE | |||
| 8 | Gland Nut | T304 Stainless Steel | |||
| 9 | Spring Washer | T304 Stainless Steel | |||
| 10 | Stem Nut | T304 Stainless Steel | |||
| 11 | Stem | T316 Stainless Steel | |||
| 12 | Spring Washer | T304 Stainless Steel | |||
| 13 | Nut | T304 Stainless Steel | |||
| 14 | Bolt | T304 Stainless Steel | |||
| 15 | Handle | T304 Stainless Steel | |||
| 16 | Handle Sleeve | PVC | |||
| 17 | Locking Device | T304 Stainless Steel | |||
| Weight | 1 lbs |
|---|---|
| Dimensions | 10 × 10 × 10 in |
Two piece full port ball valves offer a cost effective repairable line solution where positive shut-off is necessary. Our fully encapsulated T316 stainless steel ball valves are easy to operate and can maintain and regulate high fluid pressures, volumes, and temperatures.
