Sanitube stainless steel clamp fittings create quick clamp nion for instant ssembly or disassembly of secure, leak proof connections. With gasket in place between two ferrule ends, clamp is secured round the joint to complete the connection.
| Size(Tube OD) | Part Number | Dimensions | ||||
| 304L | 316L | A | R | |||
| 1/2″ | — | 2CMP6-050 | 1.625 | 1.125 | ||
| 3/4″ | — | 2CMP6-075 | 1.625 | 1.125 | ||
| 1 “ | 2CMP4-1 | 2CMP6-1 | 2. | 1.5 | ||
| 1-1/2″ | 2CMP4-150 | 2CMP6-150 | 2.750 | 2.250 | ||
| 2 “ | 2CMP4-2 | 2CMP6-2 | 3.5 | 3. | ||
| 2-1/2″ | 2CMP4-250 | 2CMP6-250 | 4.250 | 3.750 | ||
| 3 “ | 2CMP4-3 | 2CMP6-3 | 5. | 4.5 | ||
| 4 “ | 2CMP4-4 | 2CMP6-4 | 6.625 | 6. | ||
| 6 “ | 2CMP4-6 | 2CMP6-6 | 9.875 | 9. | ||
| 8 “ | 2CMP4-8 | 2CMP6-8 | 12.875 | 12. | ||
Sanitube stainless steel clamp fittings create quick clamp nion for instant ssembly or disassembly of secure, leak proof connections. With gasket in place between two ferrule ends, clamp is secured round the joint to complete the connection.
Sanitube stainless steel clamp fittings create quick clamp nion for instant ssembly or disassembly of secure, leak proof connections. With gasket in place between two ferrule ends, clamp is secured round the joint to complete the connection.
